Appendix
- 94 -
(Note) Enter theDigital Output(Optical) screen to configure further settings if you use the S/PDIF Out
connector(s)onthebackpanelfordigitalaudiooutputorentertheDigital Output screen if you use
theinternalS/PDIFOutconnector(SPDIF_O)fordigitalaudiooutput.
The S/PDIF Out jack can transmit audio signals to an external decoder for decoding to get the best audio quality.
1. Connecting a S/PDIF Out Cable:
ConnectaS/PDIFcoaxialcableoraS/PDIFopticalcable(eitherone)toanexternaldecoderfortransmitting
the S/PDIF digital audio signals.
2. Configuring S/PDIF Out:
On the Digital Output(Optical) screen
(Note)
, click the Default Format tab and then select the sample rate and
bit depth. Click OK to complete.
Connects to a S/PDIF optical cable
6-2-2 ConguringS/PDIFOut
Connects to a S/PDIF coaxial cable
