Gigabyte GA-945PL-S3 User Manual

Hardware Installation- 11 -
English
Rear Panel I/O  1 PS/2 keyboard port
 1 PS/2 mouse port
 1 parallel port
 1 serial port
 4 USB 2.0/1.1 port
 1 RJ-45 ports
 6 audio jacks (Line In / Line Out / MIC In/Surround Speaker Out (Rear
Speaker Out)/Center/Subwoofer Speaker Out/Side Speaker Out)
I/O Control  IT8718 chip
Hardware Monitor  System voltage detection
 CPU temperature detection
 CPU / Power / System fan speed detection
 CPU warning temperature
 CPU / Power / System fan failure warning
 Supports CPU Smart Fan function
BIOS  1 4 Mbit flash ROM
 Use of licensed AWARD BIOS
Additional Features  Supports @BIOS
 Supports Download Center
 Supports Q-Flash
 Supports EasyTune
(Note 2)
 Supports Xpress Install
 Supports Xpress Recovery2
 Supports Xpress BIOS Rescue
Bundle Software  Norton Internet Security (OEM version)
Form Factor  ATX form factor; 30.5cm x 19.3cm
(Note 1) Some memory configurations will result in memory frequency being reduced from 533 MHz
down to 400 MHz. (Please refer to to Page 15 for more information.)
(Note 2) EasyTune functions may vary depending on different motherboards.

Gigabyte GA-945PL-S3 Specifications

General

Number of memory slots	4
Maximum internal memory	2 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	2
S/PDIF out connector	Yes
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Motherboard form factor	ATX
LAN controller	Realtek RTL8111B
Networking features	Gigabit Ethernet

Weight and Dimensions

Depth	190 mm
Width	305 mm
