After the creation is completed, you can see detailed information about the RAID Array in the DISK/

VOLUME INFORMATION section, including RAID mode, disk block size, disk name, and disk capacity,

etc.

To exit the ICH8R RAID BIOS utility, press ESC in Main Menu.

Now, you can proceed to the installation of the SATA driver and operating system.

Delete RAID Volume

If you want to delete a RAID volume, select the Delete RAID Volume option in Main Menu. Press

ENTER and follow on-screen instructions.

Figure 9

Intel(R) Matrix Storage Manager option ROM V6.0.0.1022 ICH8R wRAID5

[ MAIN MENU ]

1. Create RAID Volume

2. Delete RAID Volume

3. Reset Disks to Non-RAID

4. Exit

[ DISK/VOLUME INFORMATION ]

RAID Volumes :

ID Name Level Strip Size Status Bootable

0 Volume0 RAID0(Stripe) 128KB 223.6GB Normal Yes

Physical Disks :

Port Drive Model Serial # Size Type/Status(Vol ID)

0 ST3120026AS 3JT354CP 111.8GB Member Disk(0)

1 ST3120026AS 3JT329JX 111.8GB Member Disk(0)

[]-Select [ESC]-Exit [ENTER]-Select Menu
