- 11 - Hardware Installation
Storage Interface Chipset:
- 5 x SATA 6Gb/s connectors supporting up to 5 SATA 6Gb/s devices
- 1 x eSATA 6Gb/s port on the back panel supporting up to 1 SATA 6Gb/s
device
* Actual transfer rate is dependent on the device being connected.
- Support for RAID 0, RAID 1, RAID 10, and JBOD
USB Chipset:
- Up to 10 USB 2.0/1.1 ports (2 ports on the back panel, 8 ports available
through the internal USB headers)
- Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available
through the internal USB header)
Etron EJ168 chip:
- Up to 2 USB 3.0/2.0 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
5 x SATA 6Gb/s connectors
1 x APU fan header
2 x system fan headers
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
4 x USB 2.0/1.1 headers
1 x USB 3.0/2.0 header
1 x serial port header
1 x Trusted Platform Module (TPM) header
1 x clearing CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
1 x optical S/PDIF Out connector
2 x USB 2.0/1.1 ports
4 x USB 3.0/2.0 ports
1 x eSATA 6Gb/s port
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker
Out/Line In/Line Out/Microphone)
I/O Controller iTE IT8720 chip
