Gigabyte GA-A55-DS3P User Manual

Appendix - 72 -
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
Step 2:
Save changes and exit BIOS Setup.
Figure 1
B. Conguring SATA controller mode in BIOS Setup
Make sure to congure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test).
Make sure OnChip SATA Controller is enabled. To enable RAID for the SATA3_0/1/2/3 connectors, set On-
Chip SATA Type to RAID. To enable RAID for the SATA3_4/eSATA connectors, set OnChip SATA Type to
RAID and set OnChip SATA Port4/5 Type to As SATA Type (Figure 1).
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Integrated Peripherals
 OnChipSATAController  [Enabled]
 OnChipSATAType   [RAID]
OnChip SATA Port4/5 Type [AsSATAType]
x OnChip SATA Port as ESP Press Enter
 OnboardLANFunction  [Enabled]
 OnboardLANBootROM  [Disabled]

 SMARTLAN    [PressEnter]
 OnboardAudioFunction  [Enabled]
 OnboardUSB3.0Controller  [Enabled]
 USBControllers    [Enabled]
 USBLegacyFunction   [Enabled]
 USBStorageFunction   [Enabled]
 OnboardSerialPort1   [3F8/IRQ4]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

