Appendix - 76 -
Delete an Array
The Delete Array menu option allows for deletion of disk array assignments.
Deleting an existing disk array could result in loss of data. Record all array information including the
array type, the disk members, and stripe block size in case you wish to undo a deletion.
1. To delete an array, press <3> in the Main Menu to enter the Delete LD Menu. Then highlight the array you
wish to delete and press the <Delete> key or the <Alt>+<D> keys.
2. The View LD Denation Menu will appear (as shown in Figure 10) showing which drives are assigned to
this array. Press <Ctrl>+<Y> if you are sure to delete the array or other keys to abort.
3. When the array is deleted, the screen will return to Delete LD Menu. Press <Esc>to return to Main Menu.
Figure 10
View Drive Assignments
The View Drive Assignments option in the Main Menu displays whether the attached hard drives are as-
signed to a disk array or are unassigned. Under the Assignment column, drives are labeled with their as-
signed disk array or shown as Free if unassigned.
Figure 9
Option ROM Utility (c) 2011 Advanced Micro Devices, Inc.
[KeysAvailable]
[ViewDrivesAssignments]
[
h
]Up[
i
]Down[PaUp/PaDn]SwitchPage[Ctrl+H]SecureErase
[ESC]Exit
Port:ID DriveModel CapabilitiesCapacity(GB) Assignment
01:00 WDC WD800JD-22LSA0 SATA 3G 79.89
[S.M.A.R.T.] Health
Extent 1 79.82 LD 1-1
02:00 WDC WD800JD-22LSA0 SATA 3G 80.2
[S.M.A.R.T.] Health
Extent 1 80.02 LD 1-2
[KeysAvailable]
Option ROM Utility (c) 2011 Advanced Micro Devices, Inc.
[ViewLDDenationMenu]
[KeysAvailable]
[DrivesAssignments]
Port:ID DriveModel CapabilitiesCapacity(GB)
01:00 WDC WD800JD-22LSA0 SATA 3G 79.89
02:00 WDC WD800JD-22LSA0 SATA 3G 80.02
Press Ctrl-Y to delete the data in the disk!
orpressanyotherkeytoabort...
LD No LD Name RAID Mode Drv Capacity(GB)
LD 1 GBT RAID 0 2 80
Stripe Block 64KB
Read Policy Read Ahead Write Policy WriteBack
