Gigabyte GA-AX370-Gaming K7 User Manual

Storage Interface  Chipset:
- 2 x SATA Express connectors
- 8 x SATA 6Gb/s connectors
 - SupportforRAID0,RAID1,andRAID10
 * Referto"1-8InternalConnectors,"fortheinstallationnoticesfortheM.2andSATA
connectors.
Multi-Graphics
Technology
 Support for NVIDIA
®
Quad-GPU SLI
™
and2-WayNVIDIA
®
SLI
™
technologies
 Support for AMD Quad-GPU CrossFire
™
and2-WayAMDCrossFire
™
technologies
USB  ASMedia
®
USB 3.1 Gen 2 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
 - 1xUSB3.1Gen2Type-Aport(red)onthebackpanel
 Chipset:
 - 2xUSB3.1Gen2Type-Aports(red)onthebackpanel
- 6 x USB 3.1 Gen 1 ports (2portsonthebackpanel,4portsavailablethrough
theinternalUSBheaders)
- 4xUSB2.0/1.1ports(availablethroughtheinternalUSBheaders)
 CPU:
- 4 x USB 3.1 Gen 1 ports on the back panel
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x U.2 connector
 1 x M.2 Socket 3 connector
 2 x SATA Express connectors
 8 x SATA 6Gb/s connectors
 1 x CPU fan header
 1 x water cooling CPU fan header
 4 x system fan headers
 2 x system fan/water cooling pump headers
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 2 x USB 3.1 Gen 1 headers
 2 x USB 2.0/1.1 headers
 1xTrustedPlatformModule(TPM)header
 1xCPUcoolerLEDstrip/RGBLEDstripextensioncableheader
 1xRGB(RGBW)LEDstripextensioncableheader
 2 x temperature sensor headers
 1 x Clear CMOS jumper
 1 x power button
 1 x reset button
 1 x Clear CMOS button
 1 x OC button
 2 x BIOS switches
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x HDMI port
 1 x USB Type-C
™
port, with USB 3.1 Gen 2 support
 3xUSB3.1Gen2Type-Aports(red)
 6 x USB 3.1 Gen 1 ports
 2xRJ-45ports
 1 x optical S/PDIF Out connector
- 7 -

Gigabyte GA-AX370-Gaming K7 Specifications

General

Form Factor	ATX
Chipset	AMD X370
CPU Socket	AM4
Memory Type	DDR4
Memory Slots	4
Maximum Memory	64 GB
PCIe 2.0 x1 Slots	3
SATA 6Gb/s Ports	6
M.2 Slots	1
USB 3.1 Gen 2 Type-A Ports	1
USB 3.1 Gen 2 Type-C Ports	1
USB 3.1 Gen 1 Ports (Rear)	4
Audio	Realtek ALC1220
RAID Support	0, 1, 10
Memory Speed	2133/2400/2667/2933/3200 MHz (OC)
Multi-GPU Support	2-Way NVIDIA SLI
LAN	Intel GbE LAN
PCIe 3.0 x16 Slots	2 (x16/x0 or x8/x8 mode), 1 (x4 mode)
