Gigabyte GA-H61M-DS2 R2 User Manual

Back Panel
Connectors
 1 x PS/2 keyboard port
 1 x PS/2 mouse port
 1 x D-Sub port
 1 x parallel port
 1 x serial port
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks (Line In, Line Out, Mic In)
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  2x32Mbitash
 Use of licensed AMI UEFI BIOS
 Support for DualBIOS
™
 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features  Support for @BIOS
 Support for Q-Flash
 Support for Smart Recovery2
 Support for EasyTune
 Support for ON/OFF Charge
Bundled
Software
 Norton
®
Internet Security (OEM version)
Operating
System
 Support for Windows 8.1/8/7/Vista/XP
Form Factor  Micro ATX Form Factor; 22.6cm x 17.4cm
* GIGABYTEreservestherighttomakeanychangestotheproductspecicationsandproduct-relatedinformationwithout
prior notice.
Please visit GIGABYTE's website
for support lists of CPU, memory
modules, and SSDs.
Please visit the Support\Utility List
page on GIGABYTE's website to
download the latest version of apps.
- 7 -

Gigabyte GA-H61M-DS2 R2 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2 x DDR3 DIMM
Maximum Memory	16 GB
Audio	Realtek ALC887
Storage Interface	4 x SATA 3Gb/s
LAN	Realtek GbE LAN
Expansion Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	8 x USB 2.0
Video Outputs	1 x D-Sub
Power Connector	24-pin ATX
