Gigabyte GA-H61M-S1 User Manual

- 9 -
Back Panel
Connectors
1 x PS/2 keyboard port 
1 x PS/2 mouse port 
1 x D-Sub port 
4 x USB 2.0/1.1 ports 
1 x RJ-45 port 
3 x audio jacks (Line In/Line Out/Microphone) 
I/O Controller iTE IT8728 chip 
Hardware
Monitor
System voltage detection 
CPU/System temperature detection 
CPU/System fan speed detection 
CPU overheating warning 
CPU/System fan fail warning 
CPU/System fan speed control 
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
BIOS 1 x 32 Mbit ash 
Use of licensed AMI EFI BIOS 
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a 
Unique Features Support for @BIOS 
Support for Q-Flash 
Support for Xpress Recovery2 
Support for EasyTune 
* Available functions in EasyTune may differ by motherboard model.
Support for ON/OFF Charge 
Bundled
Software
Norton Internet Security (OEM version) 
Operating
System
Support for Microsoft 
®
Windows 7/Vista/XP
Form Factor Micro ATX Form Factor; 22.6cm x 17.4cm 
* GIGABYTE reserves the right to make any changes to the product specications and product-related information
without prior notice.

Gigabyte GA-H61M-S1 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	800, 1066, 1333, 2200 MHz
Supported memory module capacities	2GB, 4GB, 8GB
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	-
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Microsoft Windows 7/Vista/XP
Supported storage drive interfaces	SATA II
On-board graphics card	No
Parallel processing technology support	Not supported
PCI Express slots version	3.0
LAN controller	Realtek RTL8111F
Networking features	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a

Weight and Dimensions

Depth	174 mm
Width	226 mm
