- 7 -
GA-M55plus-S3G Motherboard Layout
KB_MS
ATX_12V
CPU_FAN
nVIDIA
®
GeForce 6100
SPDIF_IO
CODEC
VGA
LPT
USB
LAN
F_PANEL
BIOS
PCI3
PCI4
F_AUDIO
F_USB2F_USB1
BAT
ATX
FDD
CD_IN
GA-M55plus-S3G
PCIE_16
CI
Socket AM2
IDE1
DDRII_1
DDRII_2
DDRII_3
DDRII_4
PCIE_2
F1_1394
nVIDIA
®
nForce 430
AUDIO
USB
1394
PWR_LED
CLR_CMOS
SYS_FAN
Marvell
88E1116
COMA
F2_1394
IDE2
PCI1
PCI2
PCIE_1
TSB43AB23
SATAII0_1
IT8716
SATAII2_3
