GA-M69VM-S2 Motherboard - 62 -
English
Create Arrays Manually
To create a new array, press <2> to enter the Define LD window (Figure 5). The Define LD selection
from the Main Menu allows users to begin the process of manually defining the drive elements and
RAID levels for one or multiple disk arrays attached to the AMD SB600 controller.
Use arrow keys [KL] to move to a logical disk set and press ENTER to enter the Define LD Menu
(Figure 6).
[ Define LD Menu ] ]
[ Keys Available] ]
[K ] Up [L] Down [ESC] Exit [Enter] Select
LD No RAID Mode Total Drv Capacity (MB) Status
LD 1 ---- ---- ----- ----
LD 2 ---- ---- ----- ----
LD 3 ---- ---- ----- ----
LD 4 ---- ---- ----- ----
LD 5 ---- ---- ----- ----
LD 6 ---- ---- ----- ----
LD 7 ---- ---- ----- ----
LD 8 ---- ---- ----- ----
FastBuild (tm) Utility (c) 2006 ATI Technology, Inc.
Figure 5
[ Drives Assignments] ]
[ Keys Available] ]
LD No RAID Mode Total Drv
LD 1 RAID 0 0
Stripe Block: 64 KB Fast Init: OFF
Gigabyte Boundary: ON Cache Mode: WriteThru
[K ] Up [L] Down [ESC] Exit [Space] Change Option [Ctrl-Y] Save
Channel:ID Drive Model Capacity (MB) Assignment
1:Mas WDC WD800JD-22LSA0 80026 N
2:Mas WDC WD800JD-22LSA0 80026 N
FastBuild (tm) Utility (c) 2006 ATI Technology, Inc.
[ Define LD Menu ] ]
Figure 6
