Gigabyte GA-MA780G-UD3H User Manual

- 43 - BIOS Setup
2-4 Standard CMOS Features
Date
Sets the system date. The date format is week (read-only), month, date and year. Select the
desired field and use the up arrow or down arrow key to set the date.
Time
Sets the system time. For example, 1 p.m. is 13:0:0. Select the desired field and use the up arrow
or down arrow key to set the time.
IDE Channel 0, 1 Master/Slave
IDE HDD Auto-Detection
Press <Enter> to autodetect the parameters of the IDE/SATA device on this channel.
IDE Channel 0, 1 Master/Slave
Configure your IDE/SATA devices by using one of the three methods below:
• Auto Lets BIOS automatically detect IDE/SATA devices during the POST. (Default)
• None If no IDE/SATA devices are used, set this item to None so the system will
skip the detection of the device during the POST for faster system startup.
• Manual Allows you to manually enter the specifications of the hard drive when the
hard drive access mode is set to CHS.
Access Mode Sets the hard drive access mode. Options are: Auto (default), CHS, LBA,
Large.
IDE Channel 2, 3 Master/Slave
IDE Auto-Detection
Press <Enter> to autodetect the parameters of the IDE/SATA device on this channel.
Extended IDE Drive Configure your IDE/SATA devices by using one of the two methods below:
• Auto Lets BIOS automatically detect IDE/SATA devices during the POST. (Default)
• None If no IDE/SATA devices are used, set this item to None so the system will
skipthe detection of the device during the POST for faster system startup.
Access Mode Sets the hard drive access mode. Options are: Auto (default), Large.
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
Standard CMOS Features
Date (mm:dd:yy) Tue, Nov 11 2008
Time (hh:mm:ss) 18:25:04
 IDE Channel 0 Master [None]
 IDE Channel 0 Slave [None]
 IDE Channel 1 Master [None]
 IDE Channel 1 Slave [None]
 IDE Channel 2 Master [None]
 IDE Channel 2 Slave [None]
 IDE Channel 3 Master [None]
 IDE Channel 3 Slave [None]
Drive A [1.44M, 3.5"]
Floppy 3 Mode Support [Disabled]
Halt On [All, But Keyboard]
Base Memory 640K
Extended Memory 1790M
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Default F7: Optimized Defaults
Item Help
Menu Level

Gigabyte GA-MA780G-UD3H Specifications

General

Chipset	AMD 780G
North Bridge	AMD 780G
South Bridge	AMD SB700
Maximum Memory Supported	16GB
Channel Supported	Dual Channel
PCI Express 2.0 x16	1
PCI Express x1	2
PCI Slots	2
SATA 3Gb/s	6
Onboard Video Chipset	ATI Radeon HD 3200
Audio Chipset	Realtek ALC889A
Audio Channels	8 Channels
LAN Chipset	Realtek 8111C
Max LAN Speed	10/100/1000Mbps
eSATA	1
Form Factor	ATX
CPU Socket Type	Socket AM2+
CPU Type	Athlon 64 FX / Athlon 64 X2 / Athlon 64 / Sempron
Memory Slots	4
Memory Standard	DDR2 800/667/533
SATA RAID	0/1/10
PS/2	1 x PS/2 Keyboard + 1 x PS/2 Mouse
Video Ports	HDMI, DVI
USB 1.1/2.0	12 x USB 2.0
USB Ports	12
Audio Ports	6
S/PDIF Out	Optical
Dimensions (W x L)	30.5 cm x 24.4 cm
Power Pin	24-pin
Storage Interfaces	6 x SATA 3Gb/s, 1 x eSATA
RAID Support	RAID 0, 1, 10
