Gigabyte GA-Z97X-Gaming 5 User Manual

- 10 -
Hardware Installation
1-2 ProductSpecications
CPU  Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/
Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/
Intel
®
Celeron
®
processors in the LGA1150 package
(GotoGIGABYTE'swebsiteforthelatestCPUsupportlist.)
 L3 cache varies with CPU
Chipset
 Intel
®
Z97 Express Chipset
Memory  4 x DDR3 DIMM sockets supporting up to 32 GB of system memory
  * DuetoaWindows32-bitoperatingsystemlimitation,whenmorethan4GBofphysical
memoryisinstalled,theactualmemorysizedisplayedwillbelessthanthesizeof
the physical memory installed.
 Dual channel memory architecture
 SupportforDDR31600/1333MHzmemorymodules
 Support for non-ECC memory modules
 SupportforExtremeMemoryProle(XMP)memorymodules
 (GotoGIGABYTE'swebsiteforthelatestsupportedmemoryspeedsandmemory
modules.)
Onboard
Graphics
 Integrated Graphics Processor:
 - 1xD-Subport,supportingamaximumresolutionof1920x1200@60Hz
 - 1xDVI-Dport,supportingamaximumresolutionof1920x1200@60Hz
 * TheDVI-DportdoesnotsupportD-Subconnectionbyadapter.
 - 1xHDMIport,supportingamaximumresolutionof4096x2160@24Hzor
2560x1600@60Hz
* SupportforHDMI1.4aversion.
- Support for up to 3 displays at the same time
- Maximum shared memory of 1 GB
Audio  Realtek
®
ALC1150 codec
 Support for Sound Blaster X-Fi MB3
 HighDenitionAudio
 2/4/5.1/7.1-channel
 Support for S/PDIF Out
LAN
 Qualcomm
®
AtherosKillerE2201LANchip(10/100/1000Mbit)
Expansion Slots  1xPCIExpressx16slot,runningatx16(PCIEX16)
 * Foroptimumperformance,ifonlyonePCIExpressgraphicscardistobeinstalled,
be sure to install it in the PCIEX16 slot.
 1xPCIExpressx16slot,runningatx8(PCIEX8)
 * ThePCIEX8slotsharesbandwidthwiththePCIEX16slot.WhenthePCIEX8slot
is populated, the PCIEX16 slot will operate at up to x8 mode.
 1xPCIExpressx16slot,runningatx4(PCIEX4)
  * ThePCIEX4slotsharesbandwidthwithallPCIExpressx1slots.AllPCIExpressx1
slots will become unavailable when a PCIe x4 expansion card is installed.
* Wheninstallingax8orabovecardinthePCIEX4slot,makesuretosetPCIESlot
CongurationinBIOSSetuptox4.(RefertoChapter2,"BIOSSetup,""Peripherals,"
formoreinformation.)
(ThePCIEX16andPCIEX8slotsconformtoPCIExpress3.0standard.)
 3 x PCI Express x1 slots
 (ThePCIEX4andPCIExpressx1slotsconformtoPCIExpress2.0standard.)
 1 x PCI slot

Gigabyte GA-Z97X-Gaming 5 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600, 1800, 1866, 2000, 2133, 2200, 2400, 2600, 2666, 2800, 2933, 3000 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	2
Number of SATA connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
HDMI version	1.4a
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Component for	PC
Motherboard chipset	Intel® Z97
Audio output channels	7.1 channels
Motherboard form factor	ATX
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	1000 MB
Number of displays supported	3
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit

Weight and Dimensions

Depth	225 mm
Width	305 mm
