2. Hardware Installation
2.1. Board Layout
DVI-I Connector
DVI-I
Connector
Analog LCD Monitor Analog Monitor
or
Digital LCD Monitor
DVI Output
D-Sub
Output
DVI-I to D-Sub
Adapter (Optional)
HDMI TV
Analog LCD Monitor Analog Monitor
or
D-Sub monitor Connector
(15-pin)
HDMI Connector
HDMI Connector
D-Sub monitor
Connector
(15-pin)
HDMI to DVI-I Adapter
(Optional)
Digital LCD Monitor
