- 8 -
GV-N520 Series Graphics Accelerator
2. Hardware Installation
2.1. Board Layout
DVI-I Connector
DVI-I Connector
D-Sub monitor Connector
(15-pin)
D-Sub monitor
Connector
(15-pin)
1.GV-N520OC-1GI
HDMI Connector
HDMI Connector
Digital LCD Monitor
DVI Output
HDMI TV
Analog LCD Monitor Analog Monitor
or
