- 6 -GV-R4600 Series Graphics Accelerator
2. Hardware Installation
2.1. Board Layout
D-Sub Moni-
tor Connec-
tor (15-pin)
DVI-I
Connector
Analog LCD Monitor Analog Monitor
or
DVI-I to D-Sub
Adapter
Digital LCD Monitor
DVI Output
D-Sub
Output
HDMI TV
Analog LCD Monitor Analog CRT Monitor
or
D-Sub Output
HDMI TV
HDMI
Connector
CrossFire Connector
D-Sub Monitor Connector
(15-pin)
HDMI Connector
DVI-I Connector
1. GV-R467D3-512I/GV-R465OC-1GI
