Gigabyte GV-R575OC-1GI - Hardware Installation

- 5 - Hardware Installation
2. Hardware Installation
2.1. Board Layout
HDMI Connector
DVI-I Connector
CrossFire Connector
D-Sub monitor Connector
(15-pin)
DVI-I
Connector
Digital LCD Monitor
DVI Output
HDMI TV
Analog LCD Monitor Analog Monitor
or
HDMI Connector
D-Sub monitor
Connector
(15-pin)
