1 Power Button
2 Volume Control Key
3 SD Card Reader
4 Left Button of Mouse
5 Right Button of Mouse
6 USB Port
7 Headphone Jack
8 Microphone Jack
9 Ethernet Port
Press “+” or “-” to control volume.
● Press and release the Power button to
turn on the operation system. Press “+”
to enter into GIGABYTE BIOS Setup
Utility. USB Keyboard is recomended to
use for setting up BIOS functions under
GIGABYTE BIOS Setup Utility.
● Press and release the Power button to
turn on the operation system. Press “-” to
enter into GIGABYTE System Recovery.
Use Directing Hot Key to operate
GIGABYTE Smart Recovery.
1 Microphone
2 Speakers
Tip:
Press the “-” volume button when the computer is off and the display will indicate the battery
capacity status.
Main Battery
