1-2 ProductSpecications
CPU  Support for 10th Generation Intel
®
Core
™
i9 processors/Intel
®
Core
™
i7 processors/
Intel
®
Core
™
i5 processors/Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/
Intel
®
Celeron
®
processors in the LGA1200 package
(Go to GIGABYTE's website for the latest CPU support list.)
 L3 cache varies with CPU
Chipset  Intel
®
Z490 Express Chipset
Memory  4xDDR4DIMMsocketssupportingupto128GB(32GBsingleDIMMcapacity)
of system memory
 Dualchannelmemoryarchitecture
 SupportforDDR43200/2933/2666/2400/2133MHzmemorymodules
* Tosupport3200MHz,youmustuseXMPmemory.
 Supportfor ECC Un-bufferedDIMM1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
 Supportfornon-ECCUn-bufferedDIMM1Rx8/2Rx8/1Rx16memorymodules
 SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated Graphics Processor-Intel
®
HDGraphicssupport:
- 1xDVI-Dport,supportingamaximumresolutionof1920x1200@60Hz
* TheDVI-DportdoesnotsupportD-Subconnectionbyadapter.
- 1xDisplayPort,supportingamaximumresolutionof4096x2304@60Hz
* SupportforDisplayPort1.4version,HDCP2.3,andHDR.
- 1xHDMIport,supportingamaximumresolutionof4096x2160@30Hz
* SupportforHDMI1.4versionandHDCP2.3.
 Support for up to 3 displays at the same time
 Maximum shared memory of 512 MB
Audio  Realtek
®
ALC887 codec
 HighDenitionAudio
 2/4/5.1/7.1-channel
* Tocongure7.1-channelaudio,youneedtoopentheaudiosoftwareandselect
Deviceadvanced settings >PlaybackDevice to changethe default settingrst.
PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.
LAN
 Intel
®
GbELANchip(1000 Mbit/100 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
 1 x PCI Express x16 slot, running at x4 (PCIEX4)
 1 x PCI Express x1 slot
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
Multi-Graphics
Technology
 SupportforAMDQuad-GPUCrossFire
™
and2-WayAMDCrossFire
™
technologies
Storage Interface  1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe
x4/x2SSDsupport)(M2A_SB)
 6 x SATA 6Gb/s connectors
 SupportforRAID0,RAID1,RAID5,andRAID10
 * Referto"1-7InternalConnectors,"fortheinstallationnoticesfortheM.2andSATA
connectors.
 Intel
®
Optane
™
MemoryReady
- 6 -

Gigabyte Z490M Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i9
Maximum number of SMP processors	1
HDMI version	1.4
Microphone in	Yes
USB connector type	USB Type-A, USB Type-C
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2933, 3200 MHz
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z490
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 Education x64
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, Micro SATA
Parallel processing technology support	2-Way CrossFireX, CrossFire
Number of SATA III connectors	6
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	256 Mbit
Desktop Management Interface (DMI) version	2.7
Bundled software	Norton Internet Security (OEM version) cFosSpeed

Weight and Dimensions

Width	244 mm
