- 33 -

Chapter 5 Appendix

5-1 ConguringaRAIDSet

RAID Levels

Before you begin, please prepare the following items:

This motherboard supports RAID 0, RAID 1, RAID 5, and RAID 10. Prepare the correct number of hard drives

as indicated in the table above before conguring a RAID array.

• SATA hard drives or SSDs. To ensure optimal performance, it is recommended that you use two hard drives

with identical model and capacity.

• Windows setup disc.

• An Internet connected computer.

• A USB thumb drive.

• An M.2 PCIe SSD cannot be used to set up a RAID set either with an M.2 SATA SSD or a SATA

hard drive.

• Refer to "Internal Connectors," for the installation notices for the M.2 and SATA connectors.

RAID 0 RAID 1 RAID 5k RAID 10k

Minimum

Number of Hard

Drives

≥2 2 ≥3 4

Array Capacity

Number of hard

drives * Size of the

smallest drive

Size of the smallest

drive

(Number of hard

drives -1) * Size of

the smallest drive

(Number of hard

drives/2) * Size of the

smallest drive

Fault Tolerance No Yes Yes Yes

k Only for Z690I AORUS ULTRA PLUS DDR4.

& Please visit GIGABYTE's website for details on conguring a RAID array.

https://www.gigabyte.com/WebPage/818/z690-raid.html
