PAGE 25
RADIATOR END VIEW
SIDE VIEW GENERATOR END VIEW
TOP VIEW
SENTRY−PRO DIMENSIONAL OVERVIEW PRINT OF MODEL SPV−160
DRAWING NOT TO SCALE & DIMENSIONS = IN
(4) LIFTING HOLES IN BASE:
1-1/2" DIA. HOLES ARE INSTALLED IN BASE,
FOR LIFTING EQUIPMENT. REMOVE PLASTIC
COVERS IN THESE HOLES, AND RE-INSTALL
COVERS WHEN GEN-SET IS IN PLACE.
DRY FUEL CONNECTION:
LPG OR NAT. GAS CONNECTION IS LOCATED
ON THE ENGINE END PANEL AS SHOWN.
THERE IS A 3/4" THREADED PIPE FOR
CONNECTION.
ELECTRICAL CONNECTION:
THERE ARE THREE PLUGGED HOLES, ONE
ON THE RIGHT HAND SIDE AND ONE ON THE
LEFT HAND SIDE OF GENERATOR END.
BOTH HOLES ARE FOR 3/4" CONDUIT.
FULL ACCESS SIDE PANEL DOORS:
THERE ARE LARGE ACCESS DOORS ON
BOTH SIDES OF THE GENERATOR, GIVING
TOTAL ACCESS TO CONTROLS AND
ENGINE MAINTENANCE PARTS.
EXHAUST CHUTE:
LOCATED IN THIS CHUTE, IS WHERE THE
EXHAUST PIPE AND MUFFLER RESIDES,
PLEASE KEEP CLEAR WHILE UNIT IS
RUNNING OR HOT. DO NOT INSTALL UNIT
WHERE THE EXHAUST MAY COME INTO
CONTACT WITH FLAMMABLE OBJECTS.
SEE PAGE 13 OF OWNERS GUIDE FOR
MORE INSTALLATION INFORMATION.
