Gio Electric ELEMENT - Scooter Assembly

SCOOTER ASSEMBLY
Hardware Guide
(a) 5.5cm M10
(b)4cm M8
(c) 3cm M8
(d) 2.5cm M6
(e) 2cm M6
(f) 4cm M6
(g) 2.5cm M6
(h) 2cm M6
(i) Larger
(j) Smaller
(k)
(l)
(m) M10
(n) M6
(o) Large
(p) Medium
(q)
(r)
Please note that this visual hardware
guide is for comparative reference
only. It is not to scale and actual
hardware may vary in appearance or
size.
(s)
(t) Larger
(u) Smaller
Tool List
You will need a minimum of basics of the following:
Phillips head screwdriver
Wrenches (8mm,10mm,12mm, 14mm, 19mm)
Allen Wrench (5mm)
Pliers
