9
Safety catch (see Connection of gun and hose)
Prevent accidental spraying of water.
Air outlet on plastic case and it should NOT be blocked during operation, or fire or
electric shock hazard is possible
2.
3.
TOOLS REQUIREMENT
●
Electric drill (1/2”)
●
Hammer
●
Wrench
●
Screwdriver
Chosen a location for your pressure hose reel, follow the figure 1 of the wall base
template to mark the location of 4 holes for drilling, or place the wall base itself up to
the wall to mark the location of the screw holes for drilling.
1.
FIX WALL BASE
Note: Please install the machine at a height of approximately 24-32in above the
ground to maximize the function of auto-retract.
Use a
1/2" or 12mm
diameter drill bit to drill the 4 marked holes. Hole depth is
important. You may choose to measure a 1.96in depth on the drill bit itself and mark it
with a small piece of tape so you know when you’ve drilled the appropriate depth into
2.
