9.2.2 SERIAL INTERFACE RS232 COM 1 Y COM 2
COM 1
RS232
CONNECTOR J9
COM 2
RS232
CONNECTOR J10
pin 1 - pin 1 RX
pin 2 RX pin 2 TX
pin 3 TX pin 3 GND
pin 4 GND
