GL Racing GLA Giulia - Slide Number 5

Note: Apply Team Kyosho
Ball Diff. Grease (NOT
INCLUDED) around the R4
before assembly.
P5 of 17
PI-1513 x2
PI-1517 x2
BE-3620 x2
(3x6x2mm)
BE-2525 x1
(2x5x2.5mm)
BE-4725 x1
(4x7x2.5mm)
BS-3025 x2
M2x12 PM x2
M1.2x3 PB x2
R4 x20
(M2.0 Ball)
17mm
13mm
x2
PI-1513
PI-1513
PI-1517
PI-1517
M1.2x3 PB
M1.2x3 PB
BS-3025
BS-3025
A2
D2
D1
C2
C1
P1
BE-2525
BE-4725
M1
M2
R8
J2
(8T)
J1 (8T)
N1
N5
N4
(28T)
N3
BE-3620
N2
R2
R5
R5
R4
R1
R1
R8
M2x12 PM
(Spur 34T)
Note: Suggest to apply
Black Grease (NOT
INCLUDED) around the
R2 before assembly.
