GL GLF-1 - B Bag - Parts Identification (Page 5); B Bag - 3 to 14 Sections

B Bag - 3
B-22 x2
B Bag - 4
B-23 B-24 x9
3 x 6 x 2.5
Ball Bearing
2 x 5 x 2.3
Flanged Bearing
B Bag – 5
B-27
B-26 x2
B-25 x2
(0.6xOD4.8x7.5H)
(0.5xOD4.7x7.5H)
(0.6xOD6.0x11H)
B Bag - 6
B-29 x6B-28 x3
B Bag - 7
B-30 x2
B Bag - 9B Bag - 8
B-32 x4
B-31 x2
(M2.0 x 14.5)
B Bag - 10 B Bag - 13B Bag - 12B Bag - 11
B-36 x23
B-35 x8
B-34 x6
B-33 x4
(2.3 x 4.4 x 0.5)
(2.5 Ball M1.4 x 2)
(3.5 Ball M2.0 x 4)
(3.0 Ball M2.0 x 2.5)
(3.5 Ball Nut M2.0)
Front Damper
Side Damper
Center Damper
P-5
B Bag - 14
1.5 Hex Key
1.3 Hex Key
(Options: GLF-OP-002)
(Options:
GLF-OP-001)
(Options: GLR-003-CL)
