Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com
OM005
digiTal ConTroller operaTion
Factory Settings Range of Adjustment
Set Point Operating Range† Minimum Set Point Maximum Set Point
Standard Cooler Setting
34º F 34º F to 39º F 33º F 65º F
W = White Wine
50º F 50º F to 55º F 33º F 65º F
R = Red Wine
60º F 60º F to 65º F 33º F 65º F
The refrigerator is programmed to automatically defrost four times
daily for approximately twenty minutes. During defrost, the fan
inside the cooler will remain on and the refrigeration system will turn
off. The defrost process can be activated/deactivated manually in the
quick access menu through the dEFr or pressing the Increase key for 4
seconds. Activation or deactivation will be indicated by the messages
dEFr On or dEFr OFF respectively.
The thermostat controller has an “OFF” function. The shutdown of he
control functions allows the controller to operate only as a temperature
indicator, keeping the control outputs and alarms off. The use of this
feature is enabled or disabled by the shutdown function of the control
functions. When enabled, the control functions and alarms are switched
off CtrL OFF or on Ctrl On in the quick access menu through the
CtrL option. When the control functions are off, the message OFF is
displayed alternating with the temperature and other messages. Also
is possible turn on/turn off the control functions by pressing the Quick
Access menu key for 5 seconds.
The thermostat control probe wire may become disconnected when
the compressor compartment cover and/or grill are removed. This will
result in thermostat Err 1 or Err 3 code. Service calls to reconnect the
probe wiring are not covered by factory warranty.
SignalS
Ambient sensor disconnected or out of range.
Sensor 3 disconnected or out of range.
Operation with economic setpoint.
High ambient temberature alarm (sensor1).
Low ambient temperature alarm (sensor1).
High temperature in condenser alarm (level 1). If
this signal occurs, condenser may need cleaning.
High temperature in condenser alarm (level 2).
If
this signal occurs, condenser may need cleaning.
Compressor reached the maximum time on
without reaching the SP.
Control routines off.
It indicates that the temperature for end of
defrost has not been reached.
Please contact Full Gauge Controls.
Recongure the values of the functions.
The operating temperature range is preset at the factory
according to the table below and can be adjusted up or down
within the limits shown.
Setting the desired temperature-
To access the setpoints setup menu, press Set for 2 seconds. The
message SP will appear on the display followed by the normal
setpoint set value. Use the Increase key or Decrease key to
modify the value and conrm by pressing Set. Immediately, the
message SP-E appears indicating the setting of the economic
setpoint. Again, use the Increase key or Decrease key to modify
the value and conrm by pressing Set. Finally, the - - - -
indication signals the set up completion. The setpoints can also
be adjusted individually in the quick access menu.
