2 PN-P970620 (03/2005)
Introduction ...........................................................................1
Specifications ........................................................................ 2
Owner Assistance .................................................................. 3
General Information .............................................................. 4
Bolt Size Chart ....................................................................... 4
Bolt Torque Chart ...............................................................5-6
Safety Rules........................................................................6-9
Safety Decals .................................................................. 10-11
Operation........................................................................ 12-16
Maintenance ................................................................... 17-25
Trouble Shooting................................................................. 20
Assembly ........................................................................ 26-27
Parts Identification and Drawings .................................. 28-37
Warranty .............................................................................. 38
Raking Width .............................................................................. 72 Inches
Roller Type ............................................. Bar Roller Standard 7" Diameter
Roller Angle ................................................... 15 Degrees Both Directions
Roller Gap (Bar to Smooth Roller) ...................... 1/4" - 1-1/2" Adjustable
Tires ......................................................................................... 16.5 x 6.5-8
Tire Pressure ...................................................................................... 45 psi
Weight ............................................................................................. 995 lbs
Oil Capacity of Chain Case .................................. Approximately 1.5 Pints
Tractor Three-Point Attachment ........................................................ Cat. 1
PTO Drive ................................................................................... 540 RPM
Tractor Hydraulic System............................................. One Remote Valve
Tractor PTO HP ......................................................................... 25 - 40 HP
TABLE OF CONTENTS
SPECIFICATIONS
