PORTABLE SPOT COOLER – Model 796000
ASSEMBLY PROCEDURE AND PARTS LIST
6
3
5
1. Main Unit
2. Swivel Casters
3. Condensation Water Tank
4. Water Tank Cover Plate
5. Hose Elbow
6. Flexible Hose
7. Washable Filter
8. GFIC PLUG
9. Condensation Tank Full
Indicator Lamp
10. Power Switch
6
7
RUNNING THE SPOT COOLER
1. Rotate the power knob on top of the unit clockwise (to the right) to the
LOW position. To increase airflow rotate the knob clockwise (to the
right) to the HIGH position.
2. To turn off the cooler rotate the knob in the counter clock direction (to
the left) to the OFF position.
DO NOT RESTART THE COOLER FOR 3 MINUTES
AFTER YOU HAVE TURNED IT OFF.
ADJUSTING OUTPUT DUCT
1. Pipe can be rotated 360 degrees.
2. Pipe can be tilted approximately 15 degrees (4 inches).
TROUBLESHOOTING
The spot cooler has three automatic shutoffs.
1. Overheat Shutoff protection: The cooler has an overheat protection system
in the compressor that shuts off the unit if it overheats. Overheating can
be caused by Low Voltage, high ambient temperature or air outlet
blockage. These conditions can cause the condenser to overheat. Turn
cooler off and allow unit to reset before re-starting.
2. When the water condensation tank is 75 percent full it will automatically
shut off the cooler and indicator lamp will illuminate until the tank is
emptied. To restart, turn off the cooler using the power switch on the top
of the cooler. Then empty the water tank and replace into the machine. To
restart the cooler using the power knob on top of the cooler.
3. GFIC circuit on the plug has tripped. Turn the cooler off using the knob
on top of unit then press the reset button on the plug then turn the
cooler on using the knob on the top of the unit.
