INSTRUMENTS AND CONTROLS
The steering arm and control handle
provide controls for steering, forward
and reverse speed control, braking,
raising and lowering the forks, and
horn. Control handles on all models
have a “belly-button” reversing switch
which reverses the direction of the
truck upon contact with the operator.
Control Handle
Pos. Description
11 Battery Discharge Indicator - BDI
12 Key Switch
13 Lowering Button
14 Lifting Button
15 Directional / Speed Control
16 Horn Button
17 Reversing Switch - Belly Button Switch
R8503
