26
5 Unpacking
Figures 1 - 2
- Your device is supplied pre-
assembled. The loose parts
that are included must be
installed accordingly, depend-
ing on the application.
6 Prior to initial commissioning
WARNING
BEFORE USE OBSERVE CHAPTER 2 “FOR
YOUR SAFETY”. You should aslo note
the following safety instructions:
The mains voltage must be in compli-
ance with the voltage specification
(V~) on the type plate of the charger.
4 Technical data
MULTIJET
Set – Item number(s): 000300.0000
Set incl. battery with charger – Item number(s): 000301.0000
Battery
Type: Lithium-ion
Nominal voltage: 18.0 V
Rating: 4.0 Ah
Charging station AL 1810 CV)
Input voltage: 220-240 V~ / 50/60 Hz
Output voltage: 14.4-18.0 V / DC / 3.0 A
Battery charging time: 154 Min.
Per. charging temp. range: 0 – + 45 °C
Protection class: II
MULTIJET
Pressure: 2.5 bar - max. 25.0 bar
Water connection: ½“ watrerhose / coupling
max. inlet temperature: 30 °C
max. inlet pressure: 5 bar
max. water flow rate (throughput): 210 l/h
max. suction head : 2.0 m, suction duration when using
½“" hose approx. 22 seconds
max. suction head : 2.0 m, suction duration when using
3/8" hose approx. 11.0 seconds
max. length suction hose: 5.0 m
Device weight with lance and "4 in 1 nozzle": 1.85 kg without battery / 2.20 kg
with battery
Operating time when fully charged
- Operating mode "spray" + "plant protection
products set (accessory)": approx. 80 Min.
Operating time when fully charged
- Operating mode “clean + flat jet /
needle jet / Turbo mill“: approx 11 Min.
Hand-Arm vibration value: < 1.6 m/s
2
(+/- 0.7 m/s
2
)
Measured pressure level L
PA
: 67.8 dB; k = 3.0 dB(A)
Guaranteed sound power level L
WA
: 81 dB(A)
MULTIJET.qxp_Text_GB 06.01.20 15:50 Seite 26
