GLP X5 - Page 22

technische Serviceanleitung // technical service manual
GLP German Light Products
22
34
307041273
X5 Transfer_B1 to Driver board_L1+250MM
1
35
307041348
X5 Transfer_P1P2 to PFC_CON1 +120MM
1
36
307041349
X5 PFC_CON2 to PSU_CON2 +200MM
1
37
307041366
X5 PFC and PSU to ARM PE +125MM270MM
1
38
307041284
X5 Arm to side cover PE+150MM
2
39
307041268
X5 Network_B2B3 to Ethernet_B1+100MM
2
40
307041270
X5 DMX IN_P1 to DMX OUT+115MM
1
41
307041267
X5 Driver Board_B2 to Network_B1+460MM
1
42
307041269
X5 DMX IN_P2 to Driver board_B3+475MM
1
43
307041264
X5 Line Filter_N to Transfer_N +340MM
1
44
307041263
X5 Line Filter_L to Transfer_L +350MM
1
45
307041262
X5 POWERCON HOLD_P1 to Line-Filter_P1 AC LN+110MM
1
46
307041259
X5 POWERCON IN_L to POWERCON OUT_L+75MM
1
47
307041260
X5 POWERCON IN_N to POWERCON OUT_N+85MM
1
48
307041261
X5 POWERCON IN_PE to POWERCON OUT_PE+100110MM
1
49
307041266
X5 Bottom to Arm PE+330MM
1
50
307041265
X5 Bottom to Bottom cover PE +90MM
1
