GLP X5 - Page 21

technische Serviceanleitung // technical service manual
GLP German Light Products
21
POS
CODE
NAME
QUANTITY
1
307041300
X5 LED Driver O_B1 to LED Driver O_B2+50MM
2
2
307041298
X5 LED Driver O_P1 to LED Driver O_P2+70MM
2
3
307041346
X5 LED Driver O_B3 to LED Driver I_B2 +50MM
1
4
307041299
X5 Distributor_B2 to LED Driver O_B2+130MM
1
5
307041296
X5 Distributor_P2 to LED Driver O_P2+90MM
1
6
307041297
X5 Distributor_P4 to LED Driver I_P1+120MM
1
7
307041276
X5 LED Driver O_B1 to LED Driver I_B1+50MM
1
8
307041295
X5 Distributor_P3 to LED Driver O_P1+85MM
1
9
307061207
X5 Distributor_F2 to FAN+210MM
1
10
307061206
X5 Distributor_F1 to FAN+220MM
1
11
307041290
X5 Distributor_B4 to ZOOM Driver_B1 +365MM
1
12
307041289
X5 Distributor_P5 to ZOOM Driver_P1 +365MM
1
13
307041303
X5 Distributor_B3 to Lemo AC +60MM
1
14
307041294
X5 ZOOM Driver_H1 to ZOOM Hall_H1+75MM
1
15
307041293
X5 ZOOM Driver_M1 to ZOOM Motor+240MM
1
16
307041292
X5 ZOOM Driver_H2 to ZOOM Hall_H1+320MM
1
17
307041291
X5 ZOOM Driver_M2 to ZOOM Motor+295MM
1
18
307041301
X5 Arm to Head PE +250MM
1
19
307041288
X5 Driver board_F4 to DIstributor_F4+190MM
1
20
307041304
X5 Driver board_F5 to DIstributor_F5+190MM
1
21
307041287
X5 Driver board_B1 to Distributor_B1 190MM
1
22
307041286
X5 Driver board_P1 to Distributor_P1 280MM
1
23
307061209
X5 PSU FAN+50MM
1
24
307041277
X5 Driver board_F3 to PSU FAN+415MM
1
25
307041283
X5 Driver board_E2 to Tilt ENC_P3+145MM
1
26
307041282
X5 Driver board_M2 to Tilt Motor+195MM
1
27
307061204
X5 Driver board_F12 to FAN+90MM
2
28
307041281
X5 Driver board_E1 to PAN ENC_P1+250MM
1
29
307041280
X5 Driver board_M1 to PAN Motor+210MM
1
30
307041279
X5 Driver board_B1 to PAN Hall+320MM
1
31
307041285
X5 Driver board_CON1 to Main board_CON1+70MM
1
32
307041278
X5 Driver board_P3 to Battery+190MM
1
33
307041351
X5 PSU to Driver board_P2 +700MM
1
