OPERATION
08/2012 9
2. Correct the diameter
Check the depth of cut by making a trial cut
and correct the setting if need be.
The cut should stop 0.1 0.3 mm in front of the conductor
so as not to damage it.
Blades are at sufficient safety spacing
from the conductor and remove the
insulation with a clean cut.
Blades cut too deep into the conductor.
Blade may be damaged!
Blades do not penetrate the insulation to
sufficient depth.
Blade may be damaged!
