3. INSTALLATION INSTRUCTIONS
IMPORTANT INFORMATION:
• !WARNING: When installing the Ultium PowerUP Charge Station, keep the location of the vehicles charging port in
mind so that the charging cable can reach. Mount the cable wall mount near the charging port for ease of use.
• !CAUTION: The Ultium PowerUP Charge Station location must be safe and adequate, to avoid any hazards.
• !CAUTION: This device shall be mounted at a sufficient height from ground such that the height of the
storage means for the coupling device is located between 24 inches (600mm) and 4 feet (1.2m) from ground.
NOTE: for indoor use, 24 inches (600mm) can be changed to 18 inches (460mm).
• !CAUTION: The installation of the Ultium PowerUP Charge Station requires a NEMA 14–50 outlet with ground at
the TOP position. If not available, it must be installed by a certified electrician.
• !CAUTION: Hardwire installation must be performed by a certified electrician ONLY.
• !CAUTION: If the Ultium PowerUP Charge Station is damaged during installation, stop the installation, and contact
the company (refer to SUPPORT section or further information).
• !CAUTION: Make sure the installation of the unit obeys any mandatory local rules, permits and laws.
• !CAUTION: Make sure to have approval from the property owner or condo association for the installation.
• !CAUTION: Make sure stainless-steel fasteners are used for all mounting installations.
• !CAUTION: Make sure the toggle switch is set to the 'HARDWIRE' position for hardwire installations. Failure to do
so will produce an error.
• !CAUTION: Unless paired via Bluetooth
®
the Ultium PowerUP Charge Station will operate at 6 Amp ONLY. Operating
amperage can be changed via the GM MyBrand / Ultium app.
