Know your product
Before using the palm planer, familiarise yourself with
all the operating features and safety requirements.
Use the tool only for the applications intended.
All other applications are expressly ruled out
1. On/off switch
2. Lock-off button
3. Depth adjustment knob
4. Handle
5. Dust/chip extraction port
6. Reversible blades
7. Blade barrel
8. Clamping screw
9. Moveable front base
10. Fixed rear base
11. Shavings
adaptor tube
12. Spanner
13. Blade protection foot
14. Secondary handle
