Know your product
Before using the impact wrench, familiarise yourself with
all the operating features and safety requirements.
Use the tool only for the applications intended. All other
applications are expressly ruled out.
1.Drive anvil
2. Rubber nose guard
3. Body
4. Adjustable speed control
5. Contoured pistol grip
6. Air inlet
7. Exhaust port
8. Trigger
9. Impact mechanism oil port
1 2 3
8
4
9
6
5
