Know your product
Before using the laser line generator, familiarise yourself
with all the operating features and safety requirements.
Laser line generator
1. Laser switch
2. Laser line rotating dial
3. Level vials
4. Battery cover
5. Magnetic base
6. Front locating groove
7. Rear locating groove
Leveling base
8. Vertical adjustment knob
9. Horizontal adjustment knobs
10. Locating pin
11. Mounting thread
Pin mounting base
12. Locating pin
13. Pin push buttons
14. Pin protective cover
15. Laser enhancing glasses
2
3
7
5
6
13
14
1
15
8
9
10
11
4
12
