Diagram 3
16 mm
6 mm
Trim off excess braid.
Diagram 2
Copper
braid
1 Cut back outer
plastic cover.
7 mm
2 Fold braid back
over outer cover.
3 Remove plastic
from inner wire.
4 Clamp wire and
braid in position
1 Cut back plastic cover. 2 Fold braid back and remove
plastic from inner wire.
3 Insert prepared cable into
connectors body and screw
in as far as possible.
