Goalzero Sherpa 100AC User Manual

6
USING YOUR SHERPA
• The Output Page shows real-time information for each port,
including inputs and outputs.
• A solid bar indicates the port is functioning as an output.
A lined bar indicates the port is functioning as an input to
charge the Sherpa.
• Ports are listed from left to right.
• Total wattage for all outputs is listed at the bottom of
the screen.
*TECH TIP: If you have the Sherpa plugged into a high power
source to charge it, you might notice the max wattage
available increase.
Outputs Page:
Access by pressing
INTERACTIVE SCREENS:

Goalzero Sherpa 100AC Specifications

General

Cell Chemistry	Li-ion NMC
Battery Type	Lithium-ion
Cycle Life	500 cycles to 80% capacity
Battery Capacity	94.72Wh
Ports	USB-A, USB-C, AC
Input	USB-C PD: 5-20V, up to 3A (60W max)
Output	USB-C PD: 5-20V, up to 3A (60W max)
AC Output	100W continuous, 150W peak
Weight	2 lbs (0.91 kg)
