Model
Charger(separately sold)
Power
Color temperature range
Light brightness range
RGB Color gamut
100% Illuminance(LUX)
CRI(≈)
TLCI(≈)
Bracket rotation angle
Built-in lithium battery
M1
5V2A/18W QC3.0(5V3A,9V2A,12V1.5A)
Max. 13W
2500K～8500K
0%~100%
0～360°(full colors)
Max. 1700
97
97
Main axis: 360°；Inside axis: 270°
2410mAh
Technical Data
Model
Duration (continuous output
in 100% full power)
Operation temperature
Dimension
Net weight
M1
Approx. 150 Minutes
-10~40℃
145*70*15mm
240g
To avoid damaged battery caused by overheating, a high temperature warning icon will be displayed on the screen. And the
warning icon will disappear when the temperature and the light back to normal.
Heat Protection Function
