Device Control
Video Mode Button
There are three main modes: Quad, Dual, Single/Full
Screen. Within each mode there are sub-modes to which
you can choose screen positions. Use the mode button,
located on the front panel, to select the video sub-mode.
Video Sub-Mode Selection Order
1. H Quadview: Input 1, Input 3&4, Input 2
2. 1x3 Quadview (1 lg x 3 sm): Input 1 & Input 2, 3, 4
3. 1x3 Quadview (1 lg x 3 sm): Input 2 & Input 1, 3, 4
4. 1x3 Quadview (1 lg & 3 sm): Input 3 & Input 1, 2, 4
5. 1x3 Quadview (1 lg & 3 sm): Input 4 & Input 1, 2, 3
6. Side by Side Dualview: Input 1 & Input 2
7. Side by Side Dualview: Input 3 & Input 4
8. Single Screen: Input 1
9. Single Sreen: Input 2
10. Single Screen: Input 3
11. Single Screen: Input 4
12. 2x2 Quadview: Input 1, Input 2 & Input 3, Input 4
