9.Offset
ESC
Calibrat
Default
Zero point adjustment (probe offset)
is indicated only after a calibration has been performed
10.Set h
xxxx mm
Possibility to enter reference height for 2-point-measurement, for a
different probe measuring range, or if density is unknown.
Deduct 10 mm from the current fill level as measured*, and enter the
resulting value.
If tank height “5.Height” has been indicated in cm (e.g. for probe
measuring range from 1,000 mbar), the value will be indicated in cm
here!
Cal: No
Cal: Yes
If activated (Yes), a confirmation dialog follows because from now on,
the system will not calculate with the density as entered but with a
special factor. Then, “Cal Mode” is indicated in step 1+2.
If this entry is made while the tank is almost empty, it is advisable to
perform a readjustment later on, see 11.Set V.
11.Set V
xxx.xxxL
Readjustment of the fill level indication with +/- key.
Cal: No
Cal: Yes
See 10.Set h
12.Unit
Unit: L
Unit: m
3
Unit: %
Unit: m
Default setting (3 decimal points: 999,900L)
(2 decimal points: 75.50 m
3
)
(2 decimal points: 99.50 % )
(2 decimal points: 2.50 m )
13.Round
Rounding
auto
off
2
5
10
20
50
100
Default setting
(increments of 1)
In dependence on the preset volume, one or two zeros are added.
This is to say that a selected rounding value 2..100 refers to the
4
th
indicated position (e.g. for a 100,000L tank, 10= stands for 1,000L
rounding)
14. –
19. Exit
Back to display mode
20. LCD Contr 60 Set the contrast of the LCD display
21. Info
Shows the following:
Software version V1.00
Serial number SN1234
X0 xxxx
B xxxx
22.TestI
Indication of the current mA measured value and the hex value for the
AD converter
23.TestR
Rel1 ON
Rel1 OFF
Rel2 ON
Rel2 OFF
Relay test
24.Init
Sure:No
Sure:Yes
Clear all settings (factory settings)
26. Exit Back to display mode
