59
Clean
400
Clean the transmission oil filter:
• after the first 50 hours service
• whenever the oil is changed
• after every 400 hours service
• when the red clogged oil filter indicator
light comes on
To clean the filter:
• unscrew the bolts that fix the cover
• remove the filter
• wash with gasoline or diesel fuel
• dry with compressed air
• fit the cover back on and close it.
Top up level
Check the oil level by means of the dipstick
(MIN-MAX )
If necessary, top up with oil of the
recommended type.
Change
800
Change the transmission oil with 20 kg of
new oil.
The recommended type of oil is
GIP SUPER TRACTOR UNIVERSAL
SAE 15W/40
Oil draining: plug A
Oil filling: plug with dipstick (MIN-MAX )
llow the oil to settle before checking the
new level.
Change the transmission oil filter as
necessary.
