42
TWIN WHEELS optional, only for FC Professional
With 4.00x8 tyres a twin wheel can be mounted.
Mount by placing 4 spacers (one per wheel) as shown in fig.7.
Twin wheels with disks, best if the wide version, can be mounted with 4.0x10
and 5.0x10 adjustable tyres. Use 4 spacers between the wheel disks on both
side as shown in Fig. 12.
TYRE INFLATION PRESSURES
Tyre Pressure
bar KPa
4.00x8" 2p.r. 1.1-1.2 110-120
4.0x10" 2p.r. 1 100
5.0x10" 2p.r. 1 100
6x6" 1 100
21x11.00-8" Tubeless 0.5 050
4.00x8" Garden 1.2 120
16x6.50-8” 1 100
18x6.50-8” softrack 1 100
4.7 STEERING BARS
(For FC 3+2)
The steering bars are vertically adjustable. These adjustments allow for 5
working positions. Adjust handlebar position by pushing lever n.10 fig.1.
4.8 IMPLEMENT COUPLING
The couple mounted on the mower makes implement coupling or release
extremely easy and quick.
Insert sleeve A fig.9 on the drive mechanism pushing notch C in the direction
shown by the arrow (narrow seating) until coupling B snaps completely into
position.
To release the implement, lift retainer B and push the mower back. When doing
this, release the wheels if necessary (refer to 4.3 above).
5. MAINTENANCE - CLEANING - LUBRICATION
5.1 ENGINE
Refer to engine instruction manual.
5.2 FILLING WITH OIL
5.2.1 GEARBOX
Check the level with the dipstick plug B fig.3.
