- Sicherungen für Mod. 35-37-40-1046-1047-1247
Vor dem Ersetzen einer Sicherung die Ursache beseitigen, die den Kurzschluß
verursacht hat.
Die Sicherungen üben folgende Schutzwirkungen aus, Abb.16 (Nr. 3 Abb.20):
A= Standlicht vorne rechts - hinten links, Kennzeichenbeleuchtung, 7-polige
Steckdose, Beleuchtung Multisystemlicht 7,5A
B= Abblendlicht rechts 7,5A
C= Fernlicht rechts und links, Kontrolleuchte Fernlicht 5A
D= Standlicht vorne links - hinten rechts, 7-polige Steckdose,
Arbeitsscheinwerfer. 7,5A
E= Abblendlicht links. 7,5A
F= Hupe. 10A
G= Stromanschluß Schalter der Warnblinklichtanlage, - 30, Steckverbindung
Kabinenleitung +30. 15A
H= Stromanschluß Hydrostop, Schalter Zapfwellenkupplung, Schalter
Kontrolleuchte Allradantrieb eingeschaltet, Schalter Kontrolleuchte
Handbremse. 10A
I= Stromanschluß Ansteuerung Kraftheber, Steckverbindung Steuergerät
Positions- und Zugkraftregelung. 10A
L= Stromanschluß Steckverbindung Kabinenleitung +15. 15A
M= Stromanschluß Multisysteminstrument, Magnetventil Motorabstellung. 10A
N= Stomanschluß Schalter der Warnblinklichtanlage +15, Stromanschluß
wahlweise Steckverbindung. 10A
Der Schlepper ist mit einer Hauptsicherung von 60A im inneren Teil der festen
Motorhaube (Nr. 4 Abb.20). Diese Sicherung schützt die ganze elektrische
Anlage.
