Summary of operational controls:
Raise-lower
• Lift control
• Rate regulation
Lever A
Knob n.31 fig.1
Controlled position
• Lift control
• Setting
Lever A
Potentiometer P
Controlled draft
• Lift control
• Draft setting
• Sensitivity setting
Lever A
Potentiometer S
Knob n.31 fig.1
Combined regulation
• Lift control
• Setting
Lever A
Potentiometer P
Potentiometer S
Lift link
• Setting
Knob n.31 fig.1
4.10 FRONT LIFT
(Optional)
The tractor can be equipped with a front raise/lower hydraulic lift with semi-
automatic class 1N implement hitch.
Use lever n-29 fig.1 to operate the front lift:
• Lever in neutral: lift stopped.
• Lever backwards (with spring action return) implement is raised to maximum
height. When the implement is raised all the way, release the lever
immediately so that the pressure relief valve does not cut in.
• Lever forward: implement lowered to its floating position.
If the tractor has supplementary front spooling valves, move lever 29 to the right
before raising or lowering the lift.
