6. TECHNICAL DATA Cont’d
SRT-701 CAHO
FEATURES
1. Terminal Design: adopts a special design with strong stress, provide
good connection. Its also suitably for vibrating
2. PCBs: whole series use double sided PCBs, quality can
be assured.
3. PCB’s location: be fixed by vertical type which will not be affected
by environment.
4. Cold-junction Compensation
by external type of high accuracy.
5. Control Action: heat (reverse) cool (direct) action.
SPECIFICATION:
Power Supply 110v/220v, ±10%
Input: K(CA), J(IC), Pt100
Ω
(DIN), R(PR)
Output: RELAY (250V/5A), DC24V for SSR drive,4-20mA
Controlmode: ON/OFF, P, PD
Proportional Band: 3% full Scale
Cycle Time: RELAY (16 Sec), SSR(2 Sec.)
Accuracy: ±0.3% Full Scale
Ambient Temperature: -10 “C-55” C
Power Consumption: RELAY (6W), SSR (5W)
Input Impedance: 20M ohm 500V DC
High/Low Alarm: ±10% Full Scale Adjustable
CONTROL
Model SRT-T700 SR-T701
Dimension 72mmx72mm
Input K,j,Pt100 K,J,Pt100
Temperature range 0-200°C
0-400°C
0-100°C
0-200°C
0-400°C
0-800°C/K,J
Output Relay, SSR, 4-20mA None
Control ON/OGG, P,P,PD. None
IM013B2/p12
