Goobay 44793 User Manual

Goobay®
by Wentronic GmbH | Pillmanstraße 12
38112 Braunschweig | Germany
REV2021-01-27
V1.0rs
44793, 44794
Compact HDMI™/VGA adapter incl. audio
1 Safety instructions
The user manual is part of the product and contains important information for
correct use.
• Read the user manual completely and carefully before use.
The user manual must be available for uncertainties and passing the
product.
• Keep this user manual.
• Do not open the housing.
• Do not modify product and accessories.
• Do not short-circuit connectors and circuits.
A defective device may not be put into operation, but must be protected
against further use.
• Use product, product parts and accessories only in perfect condition.
• Avoid stresses such as heat and cold, moisture and direct sunlight, mic-
rowaves, vibrations and mechanical pressure.
• In case of questions, defects, mechanical damage, trouble and other
problems, non-recoverable by the documentation, contact your dealer or
producer.
• Do not repair defective products yourself, but contact the dealer or the
manufacturer.
Not meant for children. The product is not a toy!
• Secure packaging, small parts and insulation against accidental use.
2 Description and function
2.1 Product
This product is a compact adapter that converts HDMI™ signals into VGA and
audio signals.
○ HDCP compliant
○ No external power source and no software required
2.2 Scope of delivery
Compact HDMI™/VGA adapter incl. audio connection, audio cable,
User Manual
2.3 Operating Elements
1 VGA jack
2 Audio jack
3 HDMI™ jack
4 HDMI™ plug
5 Audio cable with 2x 3.5mm jack
2.4 Specications
Article number 44793 44794
Input
HDMI™ jack
5V=, 0,5 A
HDMI™ plug
5V=, 0,5 A
Output
VGA jack
Audio jack
Max. Resolution
1920 x 1080
(1080p Full HD) @ 60 Hz
1920 x 1080
(1080p Full HD), inkl.
720p, 1600 x 1201
Dimensions (LxWxH) 48,8 x 20,1 x 15,5
Weight 21 g 24 g
Transmission
direction
HDMI™ -> VGA / Audio
Audio cable
Connections 2x 3.5 mm jack plug
Cable Length 1 m
3 Intended use
We do not permit using the device in other ways like described in
chapter "Description and Function" or in the "Safety Instructions".
Use the product only in dry interior rooms. Not attending to these
regulations and safety instructions might cause fatal accidents, injuries, and
damages to persons and property.
4 Preparation
1. Check the scope of delivery for completeness and integrity.
2. Compare the specications of all used devices and ensure compatibility.
5 Connection and operation
1. Connect your devices as shown in the illustration.
2. Disconnect all plug connections after use.
No controls need to be used during operation.
6 Maintenance, Care, Storage and Transportation
The product is maintenance-free.
NOTICE! Material damage
• Only use a dry and soft cloth for cleaning.
• Do not use detergents or chemicals.
• Store the product out the reach of children and in a dry and dust-protec-
ted ambience when not in use.
• Store cool and dry.
• Keep and use the original packaging for transport.
7 Disposal instructions
7.1 Product
According to the European WEEE directive, electrical and electronic
equipment must not be disposed with consumers waste. Its compo-
nents must be recycled or disposed apart from each other. Otherwise
contaminative and hazardous substances can damage the health and
pollute the environment.
As a consumer, you are committed by law to dispose electrical and electronic
devices to the producer, the dealer, or public collecting points at the end of the
devices lifetime for free. Particulars are regulated in national right. The symbol
on the product, in the user manual, or at the packaging alludes to these terms.
With this kind of waste separation, application, and waste disposal of used
devices you achieve an important share to environmental protection.
WEEE No: 82898622
7.2 Packaging
Packaging can be disposed of free of charge at the suitable collection
points – paper belongs in paper bins, plastics belong in yellow sacks
and glass belongs in used glass bins.
DE4535302615620
8 EU Declaration of conformity
With the CE sign Goobay®, a registered trademark of the Wentronic
GmbH ensures, that the product is conformed to the basic European
standards and directives.
9 Symbols used
For indoor use only IEC 60417- 5957
Recycling ISO 7001 - PI PF 066
- 2 -
Subject to change without notice.
User ManualEN
