Goobay 67510 - Connecting the Device; Maintenance, Care, Storage, and Transport; Product Specifications; Warranty and Liability

5 Connecting
1. Connecttheantenna
 cabletotheinput(IN)
oftheLTEblockinglter.
2. Connecttheoutputof
theLTEblockinglter
 (OUT)totheinputof
yourDVB-Treceiver.
3. MounttheLTEblocking
ltertoasuitablesurface,ifnecessary.
6 Maintenance, Care, Storage and Transport
• Thedeviceismaintenance-free.
• Alwaysdisconnecttheproductfromthedevice,whennotinuse!
• Useadryandsoftclothtocleanyourproduct.Becarefultoavoid
 scratches.Useaslightlymoistclothforheavystains.Lookoutforlive
 cables!Donotuseanycleaningsupplies.Thiscancauseburnstothe
 materials.Avoidliquidentrytothedevice.
• Avoidplaceswithhightemperatures,humidity,orplaceswhichcan
 becomewet,alsoduringmaintenance,care,storage,andtransport.
• Keeptheproductawayfromchildrenandstoreitatdryanddust-proof
 places!
• Keeptheoriginalpackingfortransportandtoavoiddamages.
7 Specications
Model 67510 67511 67512
Frequencyrange 7-790MHz(1dB)
Blockingrange 820-2050MHz(50dB)
Continuityrange 5-780MHz
Speardepth >50dB
Insertionloss <1dB
DCPass yes
Housing Cast-(RFtight)
Input Fjack Fplug IECplug
Output Fjack Fjack IECjack
Weight(g) 59 62
Dimensions(mm) 100x40x20 90x39x20
8 Warranty and Liability
• Theproducergrantsa2yearswarrantytoanewdevice.
• Asthemanufacturerhasnoinuenceoninstallation,warrantyonly
 appliestotheproductitself.
• Themanufacturerisnotliablefordamagestopersonsorproperty
